Product Specification

Model Number: S3GDWR-D91821

Output: 20dBm

Gain: 70dB

Frequency Band: GSM 900mhz +DCS1800mhz +UMTS2100

Frequency Range: 890-960mhz 1710-1880mhz 1920-2170mhz

Feature: Improve 2G 3G 4G at the same time

Coverage: 200-600sqm without barriers

Accessaries: Repeater Unit, log periodic antenna, 15m Cable, ceiling antenna, Power

Improvement: 2G GSM 3G WCDMA 4G LTE 1800.

Suitable For Countries: Africa, Europe, Asia, Oceania

Certificate: CE and ROHS.

Description:

12309582429015423

900 1800 2100 Products



12309582429013291


If you need other color ,please contact us .We will change it for you .

Elephone Signal Booster
Feature:
1. cover: 200-500 square meters without obstacles
2. improve Gsm 900 Lte 1800 and Wcdma 2100 at the same time
3. led light indicates the state of the signal.
4. Support different operators who has GSM 900 1800 or WCDMA 2100 frequency band
5. easy to install. This signal amplifier kit includes everything you need.
6. one year warranty.

Specification:
1. Gain: 70dB (DL); 65dB (UL)
2. power output: 20dBm
3. GSM: up to link 890-915 mhz; down link 935-960 mhz
    DCS: up to 1710-1785 mhz; down link 1805-1880 mhz
    WCDMA: up to 1920-1980 mhz link; down link 2110-2170 mhz
4. impedance: 50ohm
5. Connector Type: N Female Connector

packaging:
1.Signal Booster
2.Outdoor signal antenna
3.Indoor signal antenna(with 3M cable)
4.15m 50ohm Cable
5.English manual

installation steps:
1. Fix the reception of the roof outdoor antenna or the high place and the turn signal point.
2. Connect the external antenna to repeater machine '' BTS '' port via cable.
3. Connect indoor antenna to repeater '' MOBILE '' port.
4. AC plug power cord into the power source and finished.
5. TIP: An outdoor antenna should be "isolated" from the internal antenna, that is, it must be constructive  obstacles (walls, partitions, etc.) between the antennas.

Note:when outdoor antenna and indoor antenna are separated not enough, then it will be self-oscillation. your  phone will not get any signal.

01

HTB1QrVJMcbpK1RjSZFyq6x_qFXah
S3GDWR-D-_02 S3GDWR-D-_03 S3GDWR-D-_04 S3GDWR-D-_05



S3GDWR-D-_09S3GDWR-D-_10S3GDWR-D-_11

 960



















2G 3G 4G Signal Booster GSM Repeater Amplifier 4G Mobile Phone GSM 900 DCS 1800 WCDMA 2100 Tir Band Cell Phone cellular Booster
